Bestwood PVC Form Colour Boards includes an advanced master-batching process where a special blend of natural PVC compound is dosed on-line with specific concentrations of pigment enabling the company to produce high quality colours easily and quickly. This means Freefoam can offer many colour products with NO LEAD TIME a significant advantage to many customers. As these are pre-painted and highly finished surface, can be directly used without painting or laminating there by saving cost and time.
Suitable for
- PU Lamination
PU Lamination
PU stands for polyurethane, A Lamination or Coating of polyurethane provides a hard, strong, and stretchable polymer protection cover over the applied product. - Bending
Bending
Bending is a process where the product is exposed to steam in order to make it pliable. Heat and moisture from steam can soften inner fibres enough so they can be bent and stretched, and when cooled down they will hold their new shape. - Cutting
Cutting
Process of cutting. - CNC
CNC
Computer Numerical Control (CNC) router is a computer-controlled cutting machine which typically mounts a hand-held router as a spindle which is used for cutting board in perfect shape and sizes. - Painting
Painting
Process of painting the board.
- Sawing
Sawing
Sawing is cutting the board logs into different shapes and sizes. Sawn board is generally cut into varying rectangular widths and lengths. - Shearing
Shearing
Shearing, also known as die cutting, is a process which cuts the board without the formation of chips or the use of burning or melting. - Punching
Punching
The process of creating a pattern or texture on the board using woodcarver's punch tool. - Drilling
Drilling
Drilling is a cutting process that uses a drill bit to cut a hole of circular cross-section in the board. - Milling
Milling
Milling is the process of machining using rotary cutters to remove material by advancing a cutter into the board.
- Rivetting
Rivetting
A pop rivet is a nail-type device that, when inserted into materials, expands or peels on the end to secure the pieces permanently. - Screwing
Screwing
Screws are handy for quickly building jigs and clamping forms, joining cabinet and furniture parts, mounting hardware and trim, and much more. Screws form strong connections between parts. - Printing
Printing
Printing onto the board is a fantastic and unique way of showcasing point-of sale displays, exhibition displays and event signage both indoors and outdoors. - Photo Mounting
Photo Mounting
A board mounted print is a print that has been mounted to a rigid thick PVC Foam board and then laminated with a UV filtering film. The lamination film provides protection against fading, fingerprints and other contaminates. - Engraving
Engraving
Engraving is a printmaking technique, in which an artist works an image or matrix of images into the board.
White
Black
Grey
Yellow
Red
Green
Orange
Blue
Coffee Brown
Ivory
Product Features
- Light-weight, super hardness surface, high glossy surface & recyclable.
- No deformation, anti-stretching, anti-corrosion & paint free.
- Waterproof, fire resistant, mothproof & moisture-resistant.
Processing Features
- Easy fabrication with conventional tools, such as blades, saws, hammers and drills.
- No surface painting needed to display a noble image of your design. Bonding together with other PVC products by PVC adhesives.
- Suitable for thermal shaping, thermal bending and fold processing. Welding according to normal welding procedure.
Application
Advertising, Printing Board Signage, Sign Board, Logo, Company Culture Wall, House Ceiling Decoration, Furniture.
Available Size
8’x4’
Available Thickness
18mm and 8mm
| Standard Specification | ||||
| Properties | Test | Unit | Value | |
| Physical | Density | DIN 53479 | g/cc | 0.50 – 0.80 |
| Hardness | DIN 53505 | Shore D | ≥ 42 | |
| Water absorption | DIN 53495 | % | ≤ 1.0 | |
| Mechanical | Tensile Strength* | DIN 53455 | MPa | ≥ 15 |
| Elongation at Break** | DIN 53455 | % | ≥ 15 | |
| Modulus of Elasticity | DIN 53457 | MPa | 900 – 1500 | |
| Izod Impact Strength | ASTM D 256 | KJ/ M² | ≥ 9.0 | |
| Charpy Impact Strength | DIN 53253 | KJ/ M² | ≥ 15 | |
| Flexural Strength | DIN 53452 | MPa | > 32 | |
| Compressive strength at 10% deformation | DIN 53421 | MPa | > 6.5 | |
| Electrical | Surface Resistivity | ASTM D 257 | Ω | > 1 x 1014 |
| Volume Resistivity | ASTM D 257 | Ω -cm | > 1 x 1015 | |
| Dielectric constant at 1 MHZ | ASTM D 150 | 1.56 | ||
| Dielectric Strength | DIN 53481 | KV/cm | ≥ 90 | |
| Thermal | Vicat Softening Temperature | DIN 53460 | °C | ≥ 73 |
| Heat Deflection Temperature @ 1.8 MPa | DIN 53461 | °C | 58 | |
| Coefficient of Linear Expansion | DIN 53752 | mm/m °C | 0.08 | |
| Thermal Conductivity | DIN 52616 | W/m K | 0.05 – 0.07 | |
| Flammability | UK | BS 476 Part 7 | Class 1 Y | |
| France | NFP 92 – 501 | Class M 1 | ||
| USA | UL 94 | V 0 | ||
